30 Watt 50w Outdoor Led Street Lights Public Lighting SKD Housings For Road

Name: 30 Watt 50w Outdoor Led Street Lights Public Lighting SKD Housings For Road
Brand: Die-casting Man
Price: 35.00 USD

Wholesale 30 Watt 50w Outdoor Led Street Lights Public Lighting SKD Housings For Road from china suppliers

Brand Name : Die-casting Man

Model Number : YASL-09-30

Certification : CE ROHS ENEC

Place of Origin : CHINA

MOQ : 1 PCS

Price : USD35.00/PCS

Supply Ability : 30pcs/per day

Delivery Time : 25 days

Packaging Details : PE bag+bubble+carton

Material : ADC 12 Aluminum

Input Wattaage : 30W

Color Temperature : 3000/4000/6500K

Luminous Flux : 8400~9600 lm

Color Rendering Index : Ra≥70

LED Lifetime : 50000h

Contact Now

Products Description

Model NO.	YASL-09-50
Power	50W
Color Temperature	3000-6500K
Efficiency	＞120LM/W
Voltage	AC90-305V
Power Factor	PF≥0.95
CRI(Ra)	Ra≥70
Ambient Temperature	-40-50℃
Ambient Humidity	20%-90%RH
Lifetime(hrs)	50000
IP Rate	IP66
Installation Pipe Diameter	Φ50/60mm
Installation Height	4-8m
Net Weight	4.0kg
Gross Weight	4.5kg
Packing Size(mm)	560250210/2pcs

Product Code	YASL-09-30	YASL-09-50	YASL-09-100	YASL-09-150
Input Wattage	40W	60W	100W	180W
Color Temperature	3000-6500K	3000-6500K	3000-6500K	3000-6500K
Luminous Flux	4200-4800lm	6600-7500 lm	11000-12500lm	19800-22500lm
Input Voltage	AC90-305V	AC90-305V	AC90-305V	AC90-305V
Frequency Range	50/60Hz	50/60Hz	50/60Hz	50/60Hz
Power Factor	PF≥0.95	PF≥0.95	PF≥0.95	PF≥0.95
Color rendering index	Ra≥70	Ra≥70	Ra≥70	Ra≥70
Temperature of Working Condition	-40-50℃	-40-50℃	-40-50℃	-40-50℃
Humidity of Working Condition	20%-90%RH	20%-90%RH	20%-90%RH	20%-90%RH
LED Lifetime	50000h	50000h	50000h	50000h
Protection Grade	IP66	IP66	IP66	IP66
Installation Pipe Diameter	⌀50-60mm	⌀50-60mm	⌀50-60mm	⌀60-70mm
Installation Height	3-6m	4-8m	8-12m	10-14m
Net Weight	2.7kg	4.0kg	6.5kg	12.8kg
Gross Weight	3.0kg	4.5kg	7.0kg	13.2kg
Packing Size(mm)	490×250×210	560×250×210	675×315×155	895×400×175

30 Watt 50w Outdoor Led Street Lights Public Lighting SKD Housings For Road

LED street light housing main features:

Streetlight manufactured entirely in aluminum-casting, with a classic and recognizable design of high-quality construction.
All elements from its advanced optical body are made of optimum quality materials. In addition, they are perfectly assembled to provide an excellent photometric distribution, very high efficiency and maximum use of energy without weakening its high
 performance: luminous intensity, uniform lighting, minimization of light pollution and glare, long lifespan and watertightness.
10KV surge arrester included. Installation diameter of Ø60mm.
Optionally suitable for control and dimming functions, suitable for any application.

Smart Controller

Die-casting Man Street light managment solution enables our clients to monitor and manage LED street lights on a
 single multi-purpose network

Company Profile

About Us

.Ningbo Die casting Man Technology Co., Ltd has rich experience in street lighting and die casting manufacturing, and is a production service factory integrated in design, production and sales. The supporting production equipment includes die casting injection machines, CNC , powder coating workshop, assembling line and testing equipment. The company supports processing, customization, OEM&ODM, assemgling, testing etc. At the same time, it has a complete product research and development team, a mature production process and a scientific quality management system.Main product range: street light, die casting injection OEM&ODM.
 Product scope of application: lighting industrial and Die casting injection industrial

 The company has always adhered to the "Never stand still on products and service" purposes, with high-quality products, good reputation, product sales all over the world. We will wholeheartedly conduct win-win cooperation with domestic and foreign merchants to develop together and create brilliance.

R&D

R&D Department

We have our own R&D department with five professional engineers. We would design your product based on your idea, sample and drawing. We have full experience on lighting fixture design especially on street light and die casting injection OEM parts.

We could accept your file from DWG, solid work, UG and STP.

Also we have full experience supplier for die casting tool which will guarantee your tool quality, lead time. tool life time and maintaining.
